– Edit ventilation systemDelete segments

Example

Suppose you want to straighten the route of the ventilation duct.

Required conditions

Workflow

  1. Select the segment by clicking . In the middle of the segment an open square appears .
  2. Click on the icon of the segment . The cursor defines the new position of the segment. A single line represents the current route.
  1. Point to the position where the bend ends and the new segment begins.
  2. Click . The operation is finished.
